Fujitsu Oracle SPARC M12-2 Service Manual page 175

Table 5-2 Active/Hot Addition Procedure of the HDD/SSD
Work
Order
1
2
3
4
5
6
7
8
5.1.3 Active/Hot Addition Workflow of the PCI Expansion
Unit
Before adding the PCI expansion unit, mount it in the rack. (See "3.3 Mounting the
SPARC M12-2 and the PCI Expansion Unit in a Rack" in the Fujitsu SPARC M12-2
Installation Guide or "3.4 Mounting the SPARC M12-2S and the PCI Expansion Unit
in a Rack" in the Fujitsu SPARC M12-2S Installation Guide.)
Table 5-3
Table 5-3 Active/Hot Addition Procedure of a PCI Expansion Unit
Work
Order
1
2
3
Task
Checking the operating condition of the
system
Switching the mode switch on the OPNL
to Service
Removing the filler unit from the SPARC
M12-2/M12-2S
Installing an HDD/SSD in the SPARC
M12-2/M12-2S
Incorporating the added HDD/SSD into
the system
Confirming that there is no problem with
the added HDD/SSD
Switching the mode switch on the OPNL
to Locked
Assigning the I/O resource to a logical
domain
shows the workflow for active/hot addition of the PCI expansion unit.
Task
Checking the operating condition of the
system
Switching the mode switch on the OPNL
to Service
Removing the PCICS from the SPARC
M12-2/M12-2S
Reference
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical
"2.3.2 OPNL Control Function"
"15.3.2 Removing a Filler
"15.4.1 Installing an HDD/SSD"
"When incorporating the
"10.6.2 Incorporating an I/O Device Into
the Physical Partition by Using the Hot
Plug Function"
"10.5.3 Checking the FRU Status After
Maintenance"
"2.3.2 OPNL Control Function"
"3.2 Operations and Commands Related
to Logical Domain Configurations" in the
Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
Reference
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical
"2.3.2 OPNL Control Function"
"12.3.1 Enabling the Removal of a PCIe
Card"
Chapter 5 FRU Addition Workflows
Domains"
Unit"
HDD/SSD" in
Domains"
153
