Table 6-21 System-Stopped/Hot Removal Procedure of a PCI Expansion Unit
Work
Order
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
*1 Reassign I/O resources to logical domains as required. For details, see "3.2.18 Configuring an I/O Device" in
the Fujitsu SPARC M12 and Fujitsu M10/SPARC M10 Domain Configuration Guide.
218 Fujitsu SPARC M12-2/M12-2S Service Manual ･ January 2023
Task
Checking the operating condition of the
system
Checking the usage status of the PCI
expansion unit to be removed
Releasing the I/O resources assigned to
the PCIe cards mounted in the PCI
expansion unit to be removed
Confirming that you can release the PCI
expansion unit to be removed (*1)
Saving logical domain configuration
information
Powering off all physical partitions
Switching the mode switch on the OPNL
to Service
Releasing the PCI expansion unit to be
removed and the link card
Removing the PCICS in which the link
card is mounted from the SPARC M12-2/
M12-2S
Removing the link card from the PCICS
Installing a PCIe card filler in the PCICS
Installing the PCICS with the installed
PCIe card filler into the SPARC M12-2/
M12-2S
Powering on all physical partitions
Confirming that there is no problem with
the system from which the PCI expansion
unit was removed
Switching the mode switch on the OPNL
to Locked
Checking the operating condition of the
system (*1)
Saving logical domain configuration
information
Reference
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical
"9.2.2 Checking the Assignment Status
of I/O Devices"
"9.3 Releasing I/O Resources From a
Logical Domain"
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical
"9.1.1 Saving Logical Domain
Configuration Information"
"9.5.2 Stopping All Physical
"2.3.2 OPNL Control Function"
PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
"12.3.1 Enabling the Removal of a PCIe
Card"
"12.3.2 Removing a PCIe Card or PCIe
Card Filler"
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
"12.4.2 Incorporating a PCIe Card Into
the System"
"10.9.1 Starting the System With an
XSCF Command"
"10.5.3 Checking the FRU Status After
Maintenance"
"2.3.2 OPNL Control Function"
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical
"9.1.1 Saving Logical Domain
Configuration Information"
Domains"
Domains"
Partitions"
Domains"
