Figure 17-3 Pulling Out the PCIe Card
5.
Pull out the XBU from the server.
You can pull the XBU out of the CMU when you open its removal lever. For
details on handling the XBU, see
Note that, for the SPARC M12-2, this step is not necessary. Proceed to step 6.
Figure 17-4 Pulling Out the XBU
440
Fujitsu SPARC M12-2/M12-2S Service Manual ･ January 2023
"20.3 Removing an
XBU."
PCIe card
XBU
