10.4 Incorporating a FRU Into the System
This section describes the following procedures:
Incorporating the SPARC M12-2S Into a Building Block Configuration
■
Incorporating the FANU
■
Incorporating the PSU
■
Incorporating the XSCFU
■
10.4.1 Incorporating the SPARC M12-2S Into a Building
Block Configuration
This section describes the procedure for incorporating the SPARC M12-2S that has
undergone maintenance into a building block configuration. This procedure is done
after the one described in
Block
Note - This procedure assumes that the cables are connected to the SPARC M12-2S that has
undergone maintenance and that the READY LED on the XSCFU is blinking.
Incorporate the SPARC M12-2S.
1.
Return to the operation screen of the replacefru command of the XSCF shell, and
enter "f".
Please execute the following steps:
1) Confirm the XSCF STANDBY LED of BB#0 is not lit.
2) Turn off the breaker of BB#0.
3) Remove BB#0.
4) Execute either the following:
4-1) After the exchanged device is connected with the system,
turn on the breaker of BB#0, and please select 'finish'.
4-2) If you want to suspend the maintenance without exchanging device,
please select 'cancel'.
[f:finish|c:cancel] : f
The following screen appears when you enter "f". Wait for the processing to
finish.
Waiting for BB#0 to enter install state.
[This operation may take up to 20 minute(s)]
(progress scale reported in seconds)
0..... 30..... 60..... 90..... 120..... 150..... 180..... 210.....
240..... 270..... 300..... 330..... 360..... done
Waiting for BB#0 to enter ready state.
338 Fujitsu SPARC M12-2/M12-2S Service Manual ･ January 2023
"9.6.1 Releasing the SPARC M12-2S From the Building
Configuration."
