Fujitsu Oracle SPARC M12-2 Service Manual page 291

NAME SERVICE
MTU MAXBW LINKPROP
vnet1 primary-vsw4@primary
1500 (*1)
PEER
MAXBW LINKPROP
primary-vsw4@primary
DISK
NAME
MPGROUP
vdisk00
(Omitted)
*1 The virtual network interfaces vnet0 and vnet1 are assigned as shown.
*2 The virtual disk vdisk00 is assigned as shown.
Check the assignment status of I/O devices.
5.
The following example shows execution of the command for checking the
assignment status of I/O resources to logical domains.
# ldm list-io
NAME
----
PCIE0
(*1)
(Omitted)
/BB0/PCI5
(*2)
(Omitted)
/BB0/CMUL/NET0/IOVNET.PF0
/BB0/CMUL/NET0/IOVNET.PF0.VF0
(*3)
*1 The root complex PCIE0 is assigned as shown to the control domain.
*2 The PCIe endpoint of PCI slot #6 of BB#00 is assigned as shown to the logical domain ldom.
*3 An I/O device with the SR-IOV virtual function enabled is assigned as shown to the control domain.
To perform maintenance on a PCIe card, write down the results output by the ldm
list-io command, because they will be needed later to restore the system after the
maintenance.
9.2.3 Checking the Usage of the HDD/SSD
To check the usage of the HDD/SSD, log in to Oracle Solaris.
This section describes how to check the configuration information for both the ZFS
mirror volumes and the RAID volumes using the hardware RAID function of the
ID DEVICE
1
MAC
00:14:4f:f8:42:2f
VOLUME
vdisk00@primary-vds0
MAC
network@1 00:14:4f:fb:4d:fe
MODE
TOUT ID DEVICE
0 disk@0
TYPE BUS
---- ---
BUS PCIE0
PCIE PCIE3
PF PCIE0
VF PCIE0
Chapter 9 Releasing FRUs From the System
MODE PVID VID
1
PVID VID MTU
1 1500
SERVER
primary (*2)
DOMAIN STATUS
------ ------
primary IOV
ldom OCC
primary
primary
269
