R8C/18 Group, R8C/19 Group
12.1.6.8 Returning from an Interrupt Routine
When the REIT instruction is executed at the end of an interrupt routine, the FLG register and PC,
which have been saved to the stack, are automatically restored. The program, that was running
before the interrupt request was acknowledged, starts running again.
Restore registers saved by a program in an interrupt routine using the POPM instruction or others
before executing the REIT instruction.
12.1.6.9 Interrupt Priority
If two or more interrupt requests are generated while a single instruction is being executed, the
interrupt with the higher priority is acknowledged.
Set bits ILVL2 to ILVL0 to select the desired priority level for maskable interrupts (peripheral
functions). However, if two or more maskable interrupts have the same priority level, their interrupt
priority is resolved by hardware, and the higher priority interrupts acknowledged.
The priority levels of special interrupts, such as reset (reset has the highest priority) and watchdog
timer, are set by hardware. Figure 12.9 shows the Priority Levels of Hardware Interrupts.
The interrupt priority does not affect software interrupts. The MCU jumps to the interrupt routine
when the instruction is executed.
Figure 12.9 Priority Levels of Hardware Interrupts
Rev.1.30 Apr 14, 2006
REJ09B0222-0130
Reset
Address break
Watchdog timer
Oscillation stop detection
Voltage monitor 2
Peripheral function
Single step
Address match
Page 83 of 233
High
Low
