R8C/18 Group, R8C/19 Group
14.3.2
Output Compare Mode
In output compare mode, an interrupt request is generated when the value of the TC register matches
the value of the TM0 or TM1 register. Table 14.12 shows the Output Compare Mode Specifications.
Figure 14.31 shows an Operating Example in Output Compare Mode.
Table 14.12
Output Compare Mode Specifications
Item
Count sources
Count operations
Count start condition
Counter stop condition
Waveform output start
condition
Waveform output stop
condition
Interrupt request
generation timing
INT3/TCIN pin function
P1_0 to P1_2 pins and
P3_0 to P3_2 pins
functions
Counter value reset timing
(2)
Read from timer
(2)
Write to timer
Select functions
NOTES:
1. When the corresponding port data is 1, the waveform is output depending on the setting of the
registers TCC1 and TCOUT. When the corresponding port data is 0, the fixed level is output (refer to
Figure 14.25 Block Diagram of CMP Waveform Output Unit).
2. Access registers TC, TM0, and TM1 in 16-bit units.
Rev.1.30
Apr 14, 2006
REJ09B0222-0130
f1, f8, f32, fRING-fast
• Increment
• The value in the TC register is set to 0000h when the count stops.
The TCC00 bit in the TCC0 register is set to 1 (count starts).
The TCC00 bit in the TCC0 register is set to 0 (count stops).
Bits TCOUT0 to TCOUT5 in the TCOUT register are set to 1 (enables CMP
(2)
output).
Bits TCOUT0 to TCOUT5 in the TCOUT register are set to 0 (disables CMP
output).
• When a match occurs in compare circuit 0 [compare 0 interrupt].
• When a match occurs in compare circuit 1 [compare 1 interrupt].
• When time C overflows [timer C interrupt].
Programmable I/O port or INT3 interrupt input
Programmable I/O port or CMP output
When the TCC00 bit in the TCC0 register is set to 0 (count stops).
• The value in the compare register can be read out by reading registers
TM0 and TM1.
• The count value can be read out by reading the TC register.
• Write to the TC register is disabled.
• The values written to registers TM0 and TM1 are stored in the compare
register in the following timings:
- When registers TM0 and TM1 are written to, if the TCC00 bit is set to 0
(count stops).
- When the counter overflows, if the TCC00 bit is set to 1 (during counting)
and the TCC12 bit in the TCC1 register is set to 0 (free-run).
- When the compare 1 matches a counter, if the TCC00 bit is set to 1 and
the TCC12 bit is set to 1 (the TC register is set to 0000h at compare 1
match).
• Timer C counter reload select function
The TCC12 bit in the TCC1 register can select whether the counter value
in the TC register is set to 0000h when the compare circuit 1 match.
• Bits TCC14 to TCC15 in the TCC1 register can be used to select the
output level when compare circuit 0 matches. Bits TCC16 to TCC17 in the
TCC1 register can be used to select the output level when compare circuit
1 matches.
• Bits TCOUT6 to TCOUT7 in the TCOUT register can select whether the
output is inverted or not.
Page 143 of 233
Specification
(1)
14. Timers
