The full-speed OTG PHY includes the following components:
•
FS/LS transceiver module used by both host and device. It directly drives transmission
and reception on the single-ended USB lines.
• Integrated ID pull-up resistor used to sample the ID line for A/B device identification.
•
DP/DM integrated pull-up and pull-down resistors controlled by the OTG_FS core
depending on the current role of the device. As a peripheral, it enables the DP pull-up
resistor to signal full-speed peripheral connections as soon as V
a valid level (B-session valid). In host mode, pull-down resistors are enabled on both
DP/DM. Pull-up and pull-down resistors are dynamically switched when the role of the
device is changed via the host negotiation protocol (HNP).
• Pull-up/pull-down resistor ECN circuit. The DP pull-up consists of two resistors
controlled separately from the OTG_FS as per the resistor Engineering Change Notice
applied to USB Rev2.0. The dynamic trimming of the DP pull-up strength allows for
better noise rejection and Tx/Rx signal quality.
• V
BUS
and session-end voltage thresholds. They are used to drive the session request
protocol (SRP), detect valid startup and end-of-session conditions, and constantly
monitor the V
• V
BUS
the SRP (weak drive).
Caution: To guarantee a correct operation for the USB OTG FS peripheral, the AHB frequency should
be higher than 14.2 MHz.
31.4.5

Embedded full speed OTG PHY

The full-speed OTG PHY includes the following components:
•
FS/LS transceiver module used by both host and device. It directly drives transmission
and reception on the single-ended USB lines.
• integrated ID pull-up resistor used to sample the ID line for A/B device identification.
•
DP/DM integrated pull-up and pull-down resistors controlled by the OTG_HS core
depending on the current role of the device. As a peripheral, it enables the DP pull-up
resistor to signal full-speed peripheral connections as soon as V
a valid level (B-session valid). In host mode, pull-down resistors are enabled on both
DP/DM. Pull-up and pull-down resistors are dynamically switched when the peripheral
role is changed via the host negotiation protocol (HNP).
•
Pull-up/pull-down resistor ECN circuit. The DP pull-up consists of 2 resistors controlled
separately from the OTG_HS as per the resistor Engineering Change Notice applied to
USB Rev2.0. The dynamic trimming of the DP pull-up strength allows to achieve a
better noise rejection and Tx/Rx signal quality.
• V
BUS
and session-end voltage thresholds. They are used to drive the session request
protocol (SRP), detect valid startup and end-of-session conditions, and constantly
monitor the V
a. The content of this section applies only to USB OTG HS.
USB on-the-go full-speed/high-speed (OTG_FS/OTG_HS)
sensing comparators with hysteresis used to detect V
supply during USB operations.
BUS
pulsing method circuit used to charge/discharge V
sensing comparators with hysteresis used to detect V
supply during USB operations.
BUS
