RM0390
32.7

HDMI-CEC registers

Refer to
32.7.1

CEC control register (CEC_CR)

Address offset: 0x00
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:3 Reserved, must be kept at reset value.
Bit 2 TXEOM: Tx End Of Message
The TXEOM bit is set by software to command transmission of the last byte of a CEC message.
TXEOM is cleared by hardware at the same time and under the same conditions as for TXSOM.
0: TXDR data byte is transmitted with EOM=0
1: TXDR data byte is transmitted with EOM=1
Note: TXEOM must be set when CECEN=1
TXEOM must be set before writing transmission data to TXDR
If TXEOM is set when TXSOM=0, transmitted message will consist of 1 byte (HEADER) only
(PING message)
Bit 1 TXSOM: Tx Start Of Message
TXSOM is set by software to command transmission of the first byte of a CEC message. If the CEC
message consists of only one byte, TXEOM must be set before of TXSOM.
Start-Bit is effectively started on the CEC line after SFT is counted. If TXSOM is set while a message
reception is ongoing, transmission will start after the end of reception.
TXSOM is cleared by hardware after the last byte of the message is sent with a positive acknowledge
(TXEND=1), in case of transmission underrun (TXUDR=1), negative acknowledge (TXACKE=1), and
transmission error (TXERR=1). It is also cleared by CECEN=0. It is not cleared and transmission is
automatically retried in case of arbitration lost (ARBLST=1).
Section 1.1 on page 51
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
for a list of abbreviations used in register descriptions.
24
23
22
Res.
Res.
Res.
8
7
6
Res.
Res.
Res.
RM0390 Rev 4
HDMI-CEC controller (HDMI-CEC)
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
TX
Res.
Res.
Res.
EOM
rs
17
16
Res.
Res.
1
0
TX
CEC
SOM
EN
rs
rw
1275/1328
1283
