I/O Modules
Technical specification of ADAM-4019+
Channel
Resolution
Input Type
Input type and temperature range
Isolation Voltage
Sampling Rate
Input Impedance
Accuracy
Power Consumption
I/O Connector Type
Burn-out Detection
3-40 ADAM 4000 Series User's Manual
Table 3-5 Technical specification of ADAM-4019+
8
16 bits
V, mV, mA, T/C
V: ±1 V , ±2.5 V, ±5 V , ±10 V
mV: ±100 mV , ±500 mV
mA: ±20 mA (with 120 Ω resister)
4~20mA (with 120 Ω resister)
Thermocouple:
J
0 to 760 °C
K
0 to 1370 °C
T -100 to 400 °C
E
0 to 1000 °C
R
500 to 1750 °C
S
500 to 1750 °C
B
500 to 1800 °C
3000 V
DC
10 samples/sec (total)
Voltage: 20 MΩ, Current: 120Ω
±0.1% or better
1.0W @ 24V
DC
10 pin plug-in terminal
4~20mA and all thermocouple input
