7.2 Counter/Frequency Module Command
7.2.1 Configuration, Counter Input and Display Command Set
Command
Syntax
%AANNTTCCFF
$AA2
$AAF
$AAM
$AABS
$AAB
#AAN
$AA8V
$AA8
$AA9(data)
7-28 ADAM 4000 Series User's Manual
Description
Sets the address, input mode, baud rate, checksum
status and/or frequency gate time for a specified
counter/frequency module
Requests the return of the configuration data from the
counter/frequency module
Requests the counter/frequency module to return the
version code of its firmware
Requests the counter/frequency module to return its
name
Set the input signal mode of the specified
counter/frequency module to either non-isolated
(TTL) or photo-isolated.
Read
the
input
counter/frequency module.
Instructs the addressed counter/ frequency module to
read the counter or frequency value of counter 0 or
counter 1 and return the acquired data.
Select whether LED will display data from the
counter/frequency module directly or from the host
computer.
Read the LED Data Origin status which determines
whether LED will display data from the counter/
frequency module directly or from the host computer
The host computer sends data to the addressed
module to display on its LED. This command is valid
only after selectting to display host computer data
($AA8V)
Digital I/O and Relay Output
Counter/Frequency Command Set
mode
of
the
specified
I/O Module
4080,
4080D
4080,
4080D
4080,
4080D
4080,
4080D
4080,
4080D
4080,
4080D
4080,
4080D
4080D
4080D
4080D
