9. ADAM-4056SO 12 channel Source-type Isolated Digital Output
Module
ADDR 0X Channel
00017
00018
00019
00020
00021
00022
00023
00024
00025
00026
00027
00028
00029 Over Current CH0-3
00030 Over Current CH4-7
00031 Over Current CH8-11
ADDR 4X Channel
40211
40212
40213
40214
40215
40216
0 Digital Output Value
1 Digital Output Value
2 Digital Output Value
3 Digital Output Value
4 Digital Output Value
5 Digital Output Value
6 Digital Output Value
7 Digital Output Value
8 Digital Output Value
9 Digital Output Value
10 Digital Output Value
11 Digital Output Value
Over Current Flag
Over Current Flag
Over Current Flag
Module Name 1
Module Name 2
Versoin 1
Versoin 2
Comm Safety Enable
Comm Safety Flag
Appendix G ADAM-4000 I/O Modbus Mapping Table G- 11
Item Attribute
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Item Attribute
R
R
R
R
R
R
G
Appendix
Memo
Memo
0x40 0x56
0x53 0x4F
0xA1 0x00
0x00 0x00
Enable:0x00 0x01
Occur: 0x00 0x01
