ADAM-4080 Command Table (Continued)
Command Syntax
$AAAG
$AAA
$AA3N(data)
$AA3N
$AA5NS
$AA5N
$AA6N
$AA7N
(Continued on following page)
Command Name
Set Gate Mode
Read Gate Mode
Set Maximum
Counter Value
Read Maximum
Counter Value
Start/Stop Counter
Read Counter
Start/Stop Status
Clear Counter
Read Overflow Flag
Command Description
Requests the specified
counter/frequency module to set its
gate mode to either high, low or
disabled
Requests the specified
counter/frequency module to return
the status of its gate mode
Sets the maximum value of counter
0 or counter 1 for the specified
counter/frequency module
Reads the maximum value of
counter 0 or counter 1 of the
specified counter/frequency module
The command orders the specified
counter/frequency module to start
or stop counting
The addressed counter frequency
module returns its status indicating
whether counting is enabled or
disabled
The command clears the counter 0
or counter 1 of the specified counter
module
The addressed module returns the
status of the overflow flag of
counter 0 or counter 1
Chapter 4 Command Set 4-37
4
Chapter
Page
No.
7-40
7-41
7-42
7-43
7-44
7-45
7-46
7-47
