I/O Modules
ADAM-4017+
Figure 3-26 ADAM-4017+ 8-ch. differential analog input module
Jumper setting (ADAM-4017+)
1. JP0~JP7
JP0~
JP7
Mapping to
Channel
2. JP12 can Enable/Disable Watchdog Timer Function. The default
setting is closed, i.e., Watchdog Timer Function Enabled. Please
always keep JP12 closed and enable/disable the watchdog timer
function in ADAM-utility.
3-30 ADAM 4000 Series User's Manual
8-channel Differential Analog Input Module
DATA
ACQUISITION
MODULE
INPUT:
STRAIN GAUGE
mV, V, mA
OUPUT:
RS-485
20 mA Input Range
Voltage Input range
Ch.
Ch.
1
2
JP 0
JP 2
ADAM-4017+
CODE
INPUT RANGE
08
±10 V
09
±5 V
0A
±1 V
0B
±500 mV
0C
±100 mV
0D
±20 mA
07
4 ~20 mA
Ch.
Ch.
Ch.5
3
4
JP 4
JP 6
JP 1
Ch.6
Ch.7
Ch.8
JP 3
JP 5
JP 7
