4011, 4011D, 4012, 4013, 4015, 4015T, 4016,
4017, 4017+, 4018, 4018+, 4018M, 4019+
Table 5-1 Input Range Codes (Type Codes)
Input Range Code (Hex)
00
01
02
03
04
05
06
0E
0F
10
11
12
13
14
Input Range Code(Hex)
08
09
0A
0B
0C
0D
Notice: The input range requires the usage of a 125 Ω current conversion resistor
Input Rage Code (Hex)
00
01
02
03
06
5-6
ADAM 4000 Series User's Manual
Input Range for 4011, 4011D, 4018, 4018+
(Thermocouple and ± 20 mA only), 4018M
± 15 mV
± 50 mV
± 100 mV
± 500 mV
± 1 V
± 2.5 V
± 20 mA
Type J Thermocouple 0 ~ 760 ℃
Type K Thermocouple 0 ~ 1370 ℃
Type T Thermocouple -100 ~ 400 ℃
Type E Thermocouple 0 ~ 1000 ℃
Type R Thermocouple 500 ~ 1750 ℃
Type S Thermocouple 500 ~ 1750 ℃
Type B Thermocouple 500 ~ 1800 ℃
Input Range for 4012,4017,4017+
± 10 V
± 5 V
± 1 V
± 500 mV
± 150 mV
± 20 mA
Input Range for 4016
±15 mV
±50 mV
±100 mV
±500 mV
±20 mA
