Technical Specifications
A.5 ADAM-4016 Analog Input/Output Module
Table A-7 ADAM-4016 Specifications
AI channel number
AI range
Output
Speed (bps)
Maximum distance
Input impedance
AI isolation voltage
AI resolution
AI sampling rate
AI accuracy
AI zero drift
AI span drift
AI CMR @ 50/60 Hz
AI NMR @ 50/60 Hz
AO channel number
AO range
AO drive current
AO isolation voltage
AO accuracy
AO drift
Digital output
Sink current
Power dissipation
Support protocol
Watchdog timer
Power requirements
Power consumption
A-12 ADAM 4000 Series User's Manual
1
±15 mV, ±50 mV, ±100 mV, ±500 mV
and ±20 mA
RS-485 (2-wire)
1200, 2400, 4800, 9600, 19.2K, 38.4K,
57.6K, 115.2K
4000 ft. (1200 m)
Voltage: 2 MΩ, Current: 125 Ω
3000 V
DC
16-bit
10 samples/second
±0.05% or better
±6 μV /℃
±25 ppm/℃
150 dB
100 dB
1
0~10 V
30 mA
3000 V
DC
0.05% of FSR
± 50 ppm/℃
4 channels open collector to 30 V
30 mA maximum load
300 mW
ADAM ASCII
1.6 second (System)
+10 to +30 V
DC
2.2 W @ 24 V
DC
(non-regulated)
