Technical Specifications
A.4 ADAM-4013 RTD Input Module
Table A-6 ADAM-4013 Specifications
RTD channel number
Input type
Output
speed (in bps)
Maximum distance
Accuracy
Zero drift
Span drift
Input connections
Isolation-rated voltage
CMR @ 50/60 Hz
NMR @ 50/60 Hz
Sampling rate
Input impedance
Support protocol
Watchdog timer
Power supply
Power consumption
A-10 ADAM 4000 Series User's Manual
1
Pt or Ni RTD
RS-485 (2-Wire)
1200, 2400, 4800, 9600, 19.2K, 38.4K,
57.6K, 115.2K
4000 ft. (1200 m.)
±0.1% or better
±3μV/℃
±25 ppm/℃
2, 3 or 4 wires
3000 V
DC
150 dB
100 dB
10 samples/second
2 MΩ
ADAM ASCII
1.6 second (System)
+10 to +30 V
DC
0.7 W @ 24 V
DC
(non-regulated)
