Advantech Data Acquisition Modules ADAM 4000 User Manual page 114

ADAM-4015/ADAM-4015T Command Table
Command Command Name
Syntax
%AANNTTCCFF Configuration
$AA2 Configuration Status
$AAF Read Firmware
Version
$AAM Read Module Name
#AA Analog Data In
#AAN Read Analog Input
from Channel N
$AA5VV Enable/Disable
Channels for
Multiplexing
$AA6 Read Channel
Status
#** Synchronized
Sampling
$AA4 Read Synchronized
Data
$AAB Channel Diagnose
$AA0Ci Single Channel
Span Calibration
$AA1Ci Single Channel
Offset Calibration
$AA7CiRrr Single Channel
Range Configuration
$AA8Ci Read Single
Channel Range
Configuration
$AAXnnnn Watchdog Timer
Setting
$AAY Read Watchdog
Timer Setting
$AAS0 Internal Calibration
$AAS1 Reload default
calibrating
parameter
Command Description
Sets the address, baud rate, data format,
checksum status, and/or integration time for a
specified analog input module
Returns the configuration parameters for the
specified analog input module
Return the firmware version code from the
specified analog input module
Return the module name from the specified
analog input module
Returns the input value from a specified analog
input module in the currently configured data
format
Returns the input value from a specified channel
of analog input module in the currently configured
data format
Enable or disable the individual channels in an
analog module
Get the enable/disable status of all channels in
an analog module
Orders all analog input modules to sample their
input values and store them in special registers
Returns the value that was stored in the specified
module's register after the #** command
Diagnose channel status in over range, under
range, and wire opening
Calibrates a specified channel to correct for gain
errors
Calibrates a specified channel to correct for offset
errors
Configure the input type and range of the
specified channel in an analog input module
Get the input type and range of the specified
channel in an analog input module
Set communication WDT cycle time from 0000 ~
9999 (unit: 0.1 second. if value is 0000, the
communication WDT function will be disable)
Read the cycle time setting of communication
WDT
Internal self-calibration for offset and gain errors
Reload factory default calibrating parameter to
overwrite current calibrating parameter
Chapter 4 Command Set 4-11
4
Chapter
Page
No.
5-4
5-10
5-12
5-13
5-14
5-16
5-17
5-18
5-21
5-22
5-24
5-27
5-28
5-29
5-30
5-31
5-32
5-33
5-34
