A.10 ADAM-4021/4024 Analog Output Module
Table A-14 ADAM-4021/4024 Specifications
Input
speed (bps)
Maximum distance
AO channel number
Output type
Output range
Accuracy
Resolution
Readback accuracy
Zero drift
voltage output
current output
Span temperature
coefficient
Isolation rated voltage
Programmable output
slope
Current load resistor
Bandwidth
Output impedance
A-24 ADAM 4000 Series User's Manual
RS-485 (2-wire)
1200, 2400, 4800, 9600, 19.2K, 38.4K,
57.6K, 115.2K
4000 ft. (1200 m)
ADAM-4021:
ADAM-4024:
mA, V
0~20 mA, 4~20 mA and ±10 V
ADAM-4021:
±0.1% of FSR for current output
±0.2% of FSR for voltage output
ADAM-4024:
±0.1% of FSR for current output
±0.1% of FSR for voltage output
12-bit
±0.1% of FSR
±30 μV/
℃
±0.2 μA/
℃
±25 ppm/
℃
3000 V
DC
0.125 to 128 mA/second
0.0625 to 64 V/second
0 to 500 Ω (source)
100 samples/second
0.5 Ω
(Table continued on next page)
1
4
(ADAM-4021 only)
