ADAM-4017+ Command Table
Command
Syntax
%AANNTTCCFF
$AA2
$AAF
$AAM
#AA
#AAN
$AA5VV
$AA6
$AA0Ci
$AA1Ci
$AA7CiRrr
$AA8Ci
$AAXnnnn
$AAY
Command Name
Configuration
Configuration
Status
Read Version
Read the Module
Name
Read Analog Input
from all Channels
Read Analog Input
from Channel N
Enable/disable
Channels for
Multiplexing
Read Channel
Status
Span Calibration
Offset Calibration
Input Range
Setting
Read Input Range
Watchdog Timer
Setting
Read Watchdog
Timer Setting
Command Description
Set the address, input range, baud rate,
data format, checksum status and/or
integration time for the specified analog
input module
Return the configuration parameters for
the specified analog input module
Return the firmware version code from the
specified analog input module
Return the module name from the
specified analog input module
Return the input values from all channels
of the specified analog input module
Return the input value from channels
number N of the specified analog input
module
Enables/disables multiplexing
simultaneously for seperate channels of
the specified input module
Ask the specified input module to return
the status of all eight channels
Gain error calibrate of assignment channel,
User have to input the external standard source
for calibrating process
Offset error calibrate of assignment channel,
User have to input the external standard source
for calibrating process
Input range setting individually
Get the input range of the assignment
channel
Set communication WDT cycle time from
0000 ~ 9999 (unit: 0.1 second. if value is
0000, the communication WDT function
will be disable)
Read the cycle time setting of
communication WDT
Chapter 4 Command Set 4-15
4
Chapter
Page
No.
5-4
5-10
5-12
5-13
5-14
5-16
5-17
5-18
5-27
5-28
5-29
5-30
5-31
5-32
