Command Set
ADAM-4080D Command Table
Command Syntax
%AANNTTCCFF
$AA2
$AAF
$AAM
$AABS
$AAB
#AAN
$AA8V
$AA8
$AA9(data)
(Continued on following page)
4-40 ADAM 4000 Series User's Manual
Command Name
Configuration
Configuration Status
Read Firmware
Version
Read Module Name
Set Input Signal
Mode
Read Input Signal
Mode
Read Counter or
Frequency Value
Select LED Data
Origin
Read LED Data
Origin
Send Data to LED
Command Description
Sets the address, input mode,
baud rate, checksum status and/or
frequency gate time for a specified
counter/ frequency module
Returns configuration parameters
from the specified
counter/frequency module
Return firmware version code from
the specified counter/frequency
module
Return the module name from the
specified counter/frequency
module
Sets the input signal mode of the
specified counter/frequency
module to either non-isolated or
photo-isolated input signals
Read the input signal mode of the
specified counter/frequency
module.
Returns the value of counter 0 or
counter 1 from a specified counter/
frequency module in hex format
Select whether LED will display
data from the counter/frequency
module directly or from the host
computer
Returns the status of the LED Data
origin. Origin is either direct from
module or from host computer
The host computer sends data to
the addressed module to display
on its LED. This command is valid
only after selectting to display host
computer data ($AA8V)
Page
No.
7-28
7-30
7-31
7-32
7-33
7-34
7-35
7-36
7-37
7-38
