Advantech Data Acquisition Modules ADAM 4000 User Manual page 218

4021
%AANNTTCCFF
Response !AA(cr)
Baud Rate Code (Hex)
Output Range Code (Hex)
NOTICE: An analog output module requires a maximum of 20
milliseconds to perform auto calibration and ranging after it is
reconfigured. During this time span, the module can not be
addressed to perform any other actions.
NOTICE: All configuration parameters can be changed dynamically,
except the checksum and baud rate parameters. They can only
be altered when the INIT* terminal is grounded. (Refer to Baud
rate and Checksum in Chapter 2).
6-4 ADAM 4000 Series User's Manual
if the command is valid.
?AA(cr) if an invalid parameter was entered or the INIT*
terminal was not grounded when changing baud rate or
checksum settings was attempted.
There is no response if the module detects a syntax or
communication error, or even if the specified address does
not exist.
! delimiter character indicates that a valid command is
received.
? delimiter character indicates that the command is invalid.
AA (range 00-FF) represents the 2-character hexadecimal
address of an analog output module.
(cr) is the terminating character, carriage return (0Dh).
Table 6-1 Baud Rate Codes
03
04
05
06
07
08
Table 6-2 Output Range Codes (Type Codes)
30
31
32
Analog Output Module Command Set
Baud Rate
1200 bps
2400 bps
4800 bps
9600 bps
19.2 Kbps
38.4 Kbps
Output Range for ADAM-4021
0 to 20 mA
4 to 20 mA
0 to 10 V
