A.15 ADAM-4056S 12-channel Sink Type Isolated Digital
Table A-19 ADAM-4056S Specifications
DO channel number
Input/Output
speed (bps)
Maximum distance
Digital output
Power dissipation
Isolation voltage
Support protocol
LED Indicator
Watchdog timer
Power supply
Power consumption
Output Module
12 digital outputs (sink type)
RS-485 (2-wire)
1200, 2400, 4800, 9600, 19.2K, 38.4K,
57.6K, 115.2K
4000 ft. (1200 m)
Open Collector to +40V
200 mA maximum
Channel: 1W maximum
Total: 2.2W (8 channels)
5000 V
DC
ADAM ASCII and MODBUS/RTU
On: Active
Off: Non-active
System (1.6 second) and communication
+10 to +30 V
DC
1.0 W @ 24 V
DC
Appendix A Technical Specification A-37
Appendix A
(non-regulated)
