ADAM-4024 Command Table
Command Syntax
%AANNTTCCFF
#AACn(data)
#AASCn(data)
#AAECn(data)
#**
$AA0Cn
$AA1Cn
$AA2
$AA3Cn(number of
counts)
$AA4
$AA5
$AA6Cn
$AA7CnRxx
$AA8Cn
$AAF
$AAM
(Continued on following page)
Command Name
Configuration
Analog Data Out
Set Startup Data
Set Emergency
Stop
N/A
4 mA Calibration
20 mA Calibration
Configuration
Status
Trim Calibration
Start-up output
current/voltage
configuration
Reset Status
Last Value
Readback
Set Output Type
Current Readback
Read Firmware
Version
Read Module
Name
Command Description
Set the address, output range,
baud rate, data format, slew rate
and/or checksum status
Directs output data to a specified
module
Set data As CHn StartUp Data
Set data As CHn Emergency
Stop Data
Synchrous Sample IDI
Tells the module to store
parameters for 4 mA Calibration
Tells the module to store
parameters for 20 mA Calibration
Read back Module status
Trims specified module a number
of units up/down
Stores a default output value in a
specified module. The output
value will take effect upon startup.
Read Back Reset Times After Last
$AA5 CMD And Clear This ounter
Returns either last value sent to
specified module by #AA
command, or start-up output
current/voltage
Set CHn Output Type
Returns measured value of the
current/voltage flowing through
current loop
Return the firmware version code
from the specified analog output
module
Return the module name from the
specified analog output module
Chapter 4 Command Set 4-25
4
Chapter
Page
No.
6-19
6-20
6-20
6-20
6-20
6-20
6-20
6-20
6-20
6-20
6-20
6-20
6-20
6-21
6-21
6-21
