- Page 1 PCL 843 16 bit Ethernet Card...
- Page 3 Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements of rights of third parties which may result from its use.
-
Page 5: Table Of Contents
Emissions ..................4 CHAPTER 2 Hardware Installation ........5 Initial inspection ..............6 PCL-843 Jumper/connector locations ........ 7 Card configuration ............... 8 Jumper settings ..............8 Configuration software/jumper (JP4) ........... 9 Interrupt (IRQ) level setting (JP2) ..........9 I/O address setup (JP1) ............... 10 Boot ROM address (JP3) ............ - Page 6 CHAPTER 3 Wiring and Networks ......... 1 7 Typical network connections ..........18 Wiring .................. 19 BNC connection ................. 19 RJ-45 connections ..............20 RJ-45 pin assignments ..............20 Diagnostics ................21 Card software diagnostics............21 LED indicator diagnostics ............22 Appendix A Quick Boot Installation Guide ....
-
Page 7: Chapter 1 Introduction
I n t r o d u c t i o n Chapter 1 Introduction... -
Page 8: Description
(Alternatively, you can use the card's jumpers.) The PCL-843 conforms to FCC Class A standards. Put a boot ROM in its supported socket and you can boot the workstation automatically from a file server without any local disk drives, excellent for operation in stand-alone and harsh industrial environments. -
Page 9: Applications
A p p l i c a t i o n s • Factory automation systems • Data acquisition systems • Networking • POS (point of sale) systems • Instrument control F e a t u r e s • Novel NE2000 compatible •... -
Page 10: Specifications
S p e c i f i c a t i o n s • Standards: IEEE 802.3 10BASE-2 and 10BASE-T • I/O Base address: 240, 280, 2C0, 300, 320, 340, 360H • Boot ROM address: Disable, C0000H, C4000H, C8000H, CC000H, D0000H, D4000H, D8000H and DC000H •... -
Page 11: Chapter 2 Hardware Installation
H a r d w a r e I n s t a l l a t i o n Chapter 2 Hardware Installation... -
Page 12: Initial Inspection
It should be free of marks and scratches and in perfect working order on receipt. As you unpack the PCL-843, check it for signs of shipping damage (damaged box, scratches, dents, etc.). If it is damaged or it fails to meet specifications, notify our service department or your local sales representative immediately. -
Page 13: Pcl-843 Jumper/Connector Locations
PCL 843 Jumper/connector locations Trouble Twisted pair shooting connector connector LEDs Configure/mode setting Boot ROM address setting Boot ROM socket selection I/O address setting Ext. LED connector Chapter 2 Hardware Installation... -
Page 14: Card Configuration
Card configuration Configuration of the PCL-843 can be done with jumpers or via the software utility. Only five parameters need to be set, these are: PCL 843 Jumper Options Selection Switches/jumpers Default Software/Jumper Selection J P 4 Jumper Setting I R Q... -
Page 15: Configuration Software/Jumper (Jp4)
Jumpers (default) Interrupt level (IRQ) setting (JP2) The PCL-843 card is designed to access interrupt levels 2 up to level 12 with the exception of 7, 8, and 9. Simply place the jumper link on the required interrupt level as shown below:... -
Page 16: I/O Address Setup (Jp1)
I/O address setup (JP1) The I/O base address the PCL-843 is selectable by a 3 position jumper, JP1. Refer to page 7 for the location of the jumper. The base address can be set anywhere in the I/O address area from hex 300H to hex 360H. -
Page 17: Mode Selection (Jp4)
*:Default Mode selection (JP4) The PCL-843 can be set to Mode 0 or Mode 1. This option is de- signed to compensate for motherboard ISA bus timing controls. For the majority of systems, select Mode 0 (default). Mode 1 is for older systems utilizing C&T chipsets, IBM 286 (or compatible) systems or... -
Page 18: Configuration Using Software
Configuration using software To set up the PCL-843's configuration using the software utility, follow the procedures below: Step 1. Ensure that jumper JP4 (pins 3 and 4) is open Step 2. Run the SETUP.EXE file located in the root directory of the software utility diskette. -
Page 19: Remote Boot Operation
Appendix A. This file gives detailed information on how to remote boot from a file server. Installing boot ROM chips After you’ve configured the PCL-843, you should install your ROM chip. These following procedures are only intended as a supplement Chapter 2 Hardware Installation... - Page 20 to the information your chip manufacturer has given you. If you are inexperienced in installing chips, you may want to read a good hardware reference book before you begin. One recommendation is by Winn L. Rosch, The Winn Rosch Hardware Bible (New York; Brady), 1989.
-
Page 21: Card Installation
(save the screw to secure the interface card retaining bracket). Remove the anti-vibration card clamp if supplied. 6. Carefully grasp the upper edge of the PCL-843 card. Align the hole in the retaining bracket with the hole on top of the expansion slot. - Page 22 PCL 843 User's Manual...
-
Page 23: Chapter 3 Wiring And Networks
Wiring and N e t w o r k s Chapter 3 Wiring and Networks... -
Page 24: Typical Network Connections
W o r k s t a t i o n W o r k s t a t i o n The PCL-843 can be connected to a network via two different media types. The cards auto-sensing function can immediately detect which type of media it is connected to. -
Page 25: Wiring
BNC connections The PCL-843 has a BNC connector, as shown below. To connect to a thin Ethernet cable you must use a BNC T-connector. If you are installing a workstation at the end of the Ethernet cable you will also need a 50Ω... -
Page 26: Connections
RJ 45 connections The PCL-843 adapter accepts an RJ-45 connector, as shown below. To connect twisted pair Ethernet (TPE) cable to the adapter, orient the connector so the key is aligned with the slot. Then gently push the connector into the receptacle until you hear or feel a click. -
Page 27: Diagnostics
To test the PCL-843 you can use the SETUP.EXE file located on the utility disk. When you run the SETUP.EXE file a menu will appear as shown on page 12. Press the "D" key for the diagnostic function and the screen shown below will appear. -
Page 28: Led Indicator Diagnostics
LED indicator diagnostics The PCL-843 also provides two diagnostic LEDs for a quick and easy display of the network status. The LED functions are as shown in the table below: PCL 843 LED Functions: GREEN Status Description Power on Flashing... -
Page 29: Appendix A Quick Boot Installation Guide
Quick Boot I n s t a l l a t i o n G u i d e Appendix A Quick Boot Installation Guide... -
Page 30: Installing Quick Boot Rom
This Appendix explains how to set up a network so that a workstation can boot from remote boot image files stored on a file server rather than from a boot diskette or hard drive located in the workstations local drive. This means a workstation relies on a PROM installed on its network board to communicate with the file server when power is applied. - Page 31 1. Create a single remote boot image file (NET$DOS.SYS) A. Boot a workstation from floppy or hard disk, and log in as SUPERVISOR. B. Insert the bootable diskette in drive A. The bootable diskette must include AUTOEXEC.BAT, drivers and shell files such as LSL, RPLODI, ETHER16, IPXODI, and NETX.
-
Page 32: Creating Multiple Remote Boot Image Files
VLM.EXE CONN.VLM (vlm files) ..NET.CFG * The contents of the asterisk marked files are: CONFIG.SYS Lastdrive=z (It is essential to have this command line) AUTOEXEC.BAT Prompt $p$g lsl rplodi ether16 ipxodi vlm f: login NET.CFG Link driver ETHER16 int 3 port 300 frame Etherent_802.3 NetWare DOS requester FIRST NETWORK DRIVE=F (the drive name) PRE- FERRED WORKGROUP=XXXX (the server name in use) 3. - Page 33 Note: You will use this information when you create the BOOTCONF.SYS file. 3. Copy the renamed .BAT file from the bootable diskette into the SYS:LOGIN directory and the default directory which is specified in the login script. Normally the default directory is the user’s home directory.
-
Page 34: Using Different Frame Types
1. In the NET.CFG file, a command “FRAME ETHERNET_xxx” is used. This has to be consistent with the frame type the network uses, even though this is the users choice to do so. For example: Frame type The command line 802.2 FRAME ETHERNET_802.2 ETHERNET_II... - Page 35 Load ETHER16 port=300 int=3 frame=ETHERNET_SNP name=ETHER_SNP Bind IPX to ETHER_SNP net=NNNNNNNN 2. No matter which Frame type is to be used, it is important to specify the frame type in the file called AUTOEXEC.NCF at the server console. (see the underlined parts in the following example) AUTOEXEC.NCF Load NE2000 port=300 int=3 frame=Ethernet_802.3 Bind IPX to NE2000 net=1994...
- Page 36 PCL 843 User's Manual...
