1. ADAM-4015 6-channel RTD Input Module and
ADAM-4015T 6-channel Thermistor Input Module
ADDR 0X Channel
00201
00202
00203
00204
00205
00206
00207
00208
ADDR 4X Channel
40001
40002
40003
40004
40005
40006
40007
40008
40201
40202
40203
40204
40205
40206
40207
40208
40211
40212
40213
40214
40221
Item
0 Burn-out Signal
1 Burn-out Signal
2 Burn-out Signal
3 Burn-out Signal
4 Burn-out Signal
5 Burn-out Signal
6 Burn-out Signal
7 Burn-out Signal
Item
0 Current Value
1 Current Value
2 Current Value
3 Current Value
4 Current Value
5 Current Value
6 Current Value
7 Current Value
0 Type Code
1 Type Code
2 Type Code
3 Type Code
4 Type Code
5 Type Code
6 Type Code
7 Type Code
Module Name 1
Module Name 2
Version 1
Version 2
Channel Enable
Appendix G ADAM-4000 I/O Modbus Mapping Table G- 3
Appendix
Attribute Memo
R 1:Burn-out
R
R
R
R
R
R
R
Attribute Memo
R
R
R
R
R
R
R
R
R/W 0x00 0x0e
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R 0x40 0x18
R 0x50 0x00
R 0xa2 0x00
R 0x00 0x00
R/W 0x00 0xff
