4011, 4011D, 4012, 4013, 4015, 4015T, 4016,
4017, 4017+, 4018, 4018+, 4018M, 4019+
Input Range Code (Hex)
02
03
04
05
07
08
09
0D
0E
0F
10
11
12
13
14
Baud Rate Code (Hex)
03
04
05
06
07
08
5-8
ADAM 4000 Series User's Manual
± 100 mV
± 500 mV
± 1 V
± 2.5 V
+4~20mA
± 10 V
± 5 V
± 20 mA
Type J Thermocouple 0 ~ 760 ℃
Type K Thermocouple 0 ~1370 ℃
Type T Thermocouple -100 ~ 400 ℃
Type E Thermocouple 0 ~ 1000 ℃
Type R Thermocouple 500 ~ 1750 ℃
Type S Thermocouple 500 ~ 1750 ℃
Type B Thermocouple 500 ~ 1800 ℃
Table 5-2 Baud Rate Codes
Input Range for 4019+
Baud Rate
1200 bps
2400 bps
4800 bps
9600 bps
19.2 kbps
38.4 kbps
