Product Specification - INVT Goodrive300-19 Series Operation Manual

Goodrive300-19 series open loop vector inverter special for hosit
Note:
1. The inverters of 380V (≥75kW) supports external DC reactors and external braking units, but
it is necessary to remove the copper tag between P1 and (+) before connecting. DC reactors
and external braking units are optional.
2. The inverters of 380V (≤55kW) supports external braking resistors which are optional.
3. Before connecting the braking resistor cable, remove the yellow labels of PB, (+), and (-)
from the terminal blocks. Otherwise, poor connection may occur.

3.3 Product specification

Function
Input voltage (V)
Power
Input current (A)
input
Input frequency (Hz)
Output voltage (V)
Output current (A)
Power
output
Output power (kW)
Output frequency (Hz)
Adjustable-speed ratio
Technical Speed fluctuation
control
Torque response
feature
Overload capability
Running
Frequency setting
control
feature
Control mode
Motor type
Speed control
accuracy
Torque control
accuracy
Starting torque
method
Specification
AC 3PH 380V(-15%)~440V(+10%)
Refer to the rated value
50Hz or 60Hz
Allowed range: 47~63Hz
0~input voltage
Refer to the rated value
Refer to the rated value
0~400Hz
SVPWM, SVC
Asynchronous motor
1: 200 (SVC)
±0.2% (SVC)
± 0.3% (SVC)
<20ms (SVC)
10% (SVC)
0.25Hz/150% (SVC)
150% of rated current: 1 minute
180% of rated current: 10 seconds
200% of rated current: 1 second
Digital setting, analog setting, pulse frequency setting,
multi-step speed
communication setting.
Switch between the combination and the set channel.
-13-
Product overview
running setting, Modbus
