INVT Goodrive300-19 Series Operation Manual page 62

Goodrive300-19 series open loop vector inverter special for hosit
Function
Name
code
Speed loop
P03.06
output filter
Compensation
coefficient of
P03.07
electromotion
slip
Compensation
P03.08 coefficient of
braking slip
Current loop
P03.09 percentage
coefficient P
Current loop
P03.10 integral
coefficient I
Torque
P03.11 setting
method
Detailed instruction of parameters
The setting range of P03.05: P03.02~P00.03 (the
Max. output frequency)
0~8 (corresponding to 0~2
Slip compensation coefficient is used to adjust the
slip frequency of the vector control and improve the
speed control accuracy of the system. Adjusting the
parameter properly can control the speed static error.
Setting range: 50%~200%
Note:
1.These two parameters adjust the PI adjustment
parameter of the current loop which affects the
dynamic response speed and control accuracy
directly. Generally, users do not need to change
the default value.
2.Only apply to the vector control mode without
PG 0 (P00.00=0).
Setting range: 0~65535
This parameter is used to enable the torque control
mode, and set the torque.
0: Torque control is invalid
1: Keypad setting torque (P03.11)
2: Analog AI1 setting torque
3: Analog AI2 setting torque
4: Analog AI3 setting torque
5: Pulse frequency HDI setting torque
6: Multi-step torque setting
7: Modbus communication setting torque
8: Reserved
9: Reserved
10: Reserved
8
/10ms)
-61-
Function parameters
Default
Modify
value
○
0
○
100%
○
100%
○
1000
○
1000
○
0
