Goodrive300-19 series open loop vector inverter special for hosit
A frequency
P00.06
command
B frequency
P00.07
command
B frequency
P00.08 command
reference
Combination
P00.09 of setting
source
Multi-function
P05.01~
digital input
P05.09
terminal
0: Keypad
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI setting
5: Reserved
6: Multi-step speed running setting
7: Reserved
8: Modbus communication setting
9~12: Reserved
13: Hierarchical multi-step speed reference
0: Keypad
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI setting
5: Reserved
6: Multi-step speed running setting
7: Reserved
8: Modbus communication setting
9~12: Reserved
13: Hierarchical multi-step speed reference
0: Maximum output frequency
1: A frequency command
0: A
1: B
2: A+B
3: A-B
4: Max (A, B)
5: Min (A, B)
10: Frequency setting increasing (UP)
11: Frequency setting decreasing (DOWN)
12: Frequency setting clear
13: Shift between A setting and B setting
