INVT Goodrive300-19 Series Operation Manual page 124

Goodrive300-19 series open loop vector inverter special for hosit
High switching
P03.05
frequency
Speed loop
P03.06
output filter
Compensation
coefficient of
P03.07
electromotion
slip
Compensation
P03.08 coefficient of
braking slip
Current loop
P03.09 percentage
coefficient P
Current loop
P03.10 integral
coefficient I
Torque
P03.11 setting
method
Keypad
P03.12
setting torque
Torque
P03.13 reference
filter time
Upper
P03.14
frequency of
P03.02~P00.03 (the Max. output frequency)
0~8 (corresponding to 0~2
50%~200%
50%~200%
0~65535
0~65535
0: Torque control is invalid
1: Keypad setting torque (P03.11)
2: Analog AI1 setting torque
3: Analog AI2 setting torque
4: Analog AI3 setting torque
5: Pulse frequency HDI setting torque
6: Multi-step torque setting
7: Modbus communication setting torque
8~10: Reserved
Note: Setting modes 2~7, 100% corresponds to three
times of the rated current of the motor.
-300.0%~300.0% (rated current of the motor)
0.000~10.000s
0: Keypad (P03.16 sets P03.14, P03.17 sets P03.15)
-123-
Basic operation instruction
8
/10ms)
10.00Hz
0
100%
100%
1000
1000
0
50.0%
0.010s
0
