INVT Goodrive300-19 Series Operation Manual page 150

Goodrive300-19 series open loop vector inverter special for hosit
Current
reference
channel
P00.09
A
B
A+B
A-B
Max(A, B)
Min(A, B)
Note: "/" means the multi-function terminal is invalid under the current reference channel.
When select multi-function terminal UP (10) and DOWN (11) to set the internal assistant frequency,
P08.44 and P08.45 can be set to increase or decrease the set frequency quickly.
UP terminal
Function selection=10
DOWN terminal
Function selection=11
Relative parameters list:
Function
Name
code
Max. output
P00.03
frequency
Upper limit of
P00.04 running
frequency
Lower limit of
P00.05 running
frequency
Multi-function terminal
function 13
Switch from A channel to
B channel
B
/
/
/
/
/
F
Sx
Sy
Detailed instruction of parameters
P00.04~400.00Hz
P00.05~P00.03
0.00Hz~P00.04
Multi-function terminal
function 14
Switch from
combination setting to
A channel
/
/
A
A
A
A
UP terminal frequency increasing integral rate P08.44
DOWN terminal frequency increasing integral rate P08.45
-149-
Basic operation instruction
Multi-function terminal
function 15
Switch from
combination setting to
B channel
/
/
B
B
B
B
T
UP terminal state
T
DOWN terminal state
T
Default
value
50.00Hz
50.00Hz
0.00Hz
