Goodrive300-19 series open loop vector inverter special for hosit
Frequency reference
Frequency setting increasing (UP)
Frequency setting decreasing (DOWN)
The mode is used in the case where the accerleration and deceleration commands are given by
button. Set P19.00 to "5: Electromotion potentiometer mode".
The forward and reverse direction signals of the hoist are given by S1 and S2, and the ACC/DEC
command is connected to S4 and S5. After start, if the ACC contact closes, the inverter will accelerate
toward 100% of speed ramp. If the ACC signal is canceled before reaching 100%, the inverter will
stop acceleration and run at current speed. If the ACC signal is given again, the inverter will continue
accelerating toward 100% speed. The DEC command goes similar to the ACC command.
If the direction command is canceled, the inverter will decelerate toward zero speed ramp. If the
direction command is closed before reaching zero speed, the inverter will stop deceleration and run at
current speed.
The parameters of electromotion potentiometer mode are as follows:
Function
code
P00.01 Running command channel
P08.44 UP/DOWN terminals control
P05.01 S1 terminal function selection
P05.02 S2 terminal function selection
P05.03 S3 terminal function selection
P05.04 S4 terminal function selection
P05.05 S5 terminal function selection
P06.03
P06.04
UP/DOWN terminal control reference
FWD running S1
REV running S2
Fault reset
S3
S4
S5
Name
Relay RO1 output
Relay RO2 output
GD300-19 inverter
Function
selection
Terminal
1
channel (LED flickering)
UP/DOWN terminals setting is
0x010
valid
1 Forward rotation operation (FWD)
2 Reverse rotation operation (REV)
7 Fault reset (RET)
Frequency
10
(UP)
Frequency
11
(DOWN)
5 Fault output
34 Brake control output
-188-
Basic operation instruction
RO1 Fault output
RO2 Brake output
AO1 Running frequency
AO2 Current output
Function instruction
running
setting
setting
command
increasing
decreasing
