Goodrive300-19 series open loop vector inverter special for hosit
Function
Name
code
of upper limit application for detailed information.
AO1 output
P06.21
filter time
Lower output
P06.22
limit of AO2
Correspondin
P06.23 g AO2 output
of lower limit
Upper output
P06.24
limit of AO2
Correspondin
P06.25 g AO2 output
of upper limit
AO2 output
P06.26
filter time
Lower output
P06.27
limit of HDO
Correspondin
P06.28 g HDO output
of lower limit
Upper output
P06.29
limit of HDO
Correspondin
P06.30 g HDO output
of upper limit
HDO output
P06.31
filter time
P07 Group Human machine interface
User's
P07.00
password
Detailed instruction of parameters
10V (20mA)
AO
0.0%
Setting range of P06.17: -100.0%~P06.19
Setting range of P06.18: 0.00V~10.00V
Setting range of P06.19: P06.17~100.0%
Setting range of P06.20: 0.00V~10.00V
Setting range of P06.21: 0.000s~10.000s
Setting range of P06.22: 0.0%~P06.24
Setting range of P06.23: 0.00V~10.00V
Setting range of P06.24: P06.22~100.0%
Setting range of P06.25: 0.00V~10.00V
Setting range of P06.26: 0.000s~10.000s
Setting range of P06.27: -100.0%~P06.29
Setting range of P06.28: 0.00~50.00kHz
Setting range of P06.29: P06.27~100.0%
Setting range of P06.30: 0.00~50.00kHz
Setting range of P06.31: 0.000s~10.000s
0~65535
The password protection will be valid when setting
any non-zero number.
00000: Clear the previous user's password, and
100.0%
-81-
Function parameters
Default
Modify
value
○
0.000s
○
0.0%
○
0.00V
○
100.0%
○
10.00V
○
0.000s
○
0.00%
○
0.00kHz
○
100.0%
○
50.00kHz
○
0.000s
○
0
