INVT Goodrive300-19 Series Operation Manual page 157

Goodrive300-19 series open loop vector inverter special for hosit
Output instructions:
Set value
0 Running frequency
1
2 Ramp reference frequency
3
Output current (relative to the
4
Output current (relative to the
5
6
7
8 Setting torque value
9
10
11
12
13
Function
Set frequency
Running speed
inverter)
motor)
Output voltage
Output power
Output torque
AI1
AI2
AI3
HDI
0~the Max. output frequency
0~ the Max. output frequency
0~ the Max. output frequency
0~2 times of the rated synchronous rotation speed of
the motor
0~2 times of the rated current of the inverter
0~2 times of the rated current of the motor
0~1.5 times of the rated voltage of the inverter
0~2 times of the rated power
0~2 times of the rated current of the motor
0~2 times of the rated current of the motor
0~10V/0~20mA
0~10V/0~20mA
-10V~10V
0.00~50.00kHz
-156-
Basic operation instruction
Instruction
