Goodrive300-19 series open loop vector inverter special for hosit
Function
Name
code
Speed
P00.00
control mode
Torque
P03.11 setting
method
Keypad
P03.12
setting torque
Torque
P03.13 reference
filter time
Upper
frequency of
P03.14 forward
rotation in
torque control
Upper
P03.15
frequency of
Detailed instruction of parameters
1: Sensorless vector control mode 1
2: SVPWM control mode
0: Torque control is invalid
1: Keypad setting torque (P03.11)
2: Analog AI1 setting torque (100% corresponds to three
times of the rated current of the motor)
3: Analog AI2 setting torque (the same as above)
4: Analog AI3 setting torque (the same as above)
5: Pulse frequency HDI setting torque (the same as above)
6: Multi-step torque setting (the same as above)
7: Modbus communication setting torque (the same as
above)
8~10: Reserved
-300.0%~300.0% (rated current of the motor)
0.000~10.000s
0: Keypad (P03.16)
1: AI1 (100% corresponds to the Max. frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDI setting upper-limit frequency (the
same as above)
5: Multi-step setting upper-limit frequency (the same as
above)
6: Modbus communication setting upper-limit frequency
(the same as above)
7~9: Reserved
0: Keypad (P03.17)
1: AI1 (100% corresponds to the Max. frequency)
-135-
Basic operation instruction
Default
value
1
0
50.0%
0.010s
0
0
