Goodrive300-19 series open loop vector inverter special for hosit Keypad operation procedure
In the stopping state, there are 10 stopping parameters can be selected to be displayed or not. They
are: set frequency, bus voltage, input terminals state, output terminals state, torque set value, AI1, AI2,
AI3, HDI, PLC and the current step of multi-step speed. P07.07 can select the parameter to be
displayed or not by bit and 》/SHIFT can shift the parameters from left to right, QUICK/JOG
(P07.02=2) can shift the parameters from right to left.
5.3.2 Displayed state of running parameters
After the inverter receives valid running commands, the inverter will enter into the running state and
the keypad will display the running parameters. RUN/TUNE LED on the keypad is on, while the
FWD/REV is determined by the current running direction which is shown as figure 5-2.
In the running state, there are 21 parameters can be selected to be displayed or not. They are:
running frequency, set frequency, bus voltage, output voltage, output current, running rotating speed,
output power, output torque, input terminals state, output terminals state, torque set value, the current
step of multi-step speed, AI1, AI2, AI3, HDI, percentage of motor overload, percentage of inverter
overload, ramp reference value, linear speed, AC input current. P07.05 and P07.06 can select the
parameter to be displayed or not by bit and 》/SHIFT can shift the parameters from left to right,
QUICK/JOG (P07.02=2) can shift the parameters from right to left.
5.3.3 Displayed state of fault
If the inverter detects the fault signal, it will enter into the fault alarm displaying state. The keypad will
display the fault code by flickering. The TRIP LED on the keypad is on, and the fault reset can be
operated by the STOP/RST on the keypad, control terminals or communication commands.
5.3.4 Displayed state of function codes editing
In the state of stopping, running or fault, press PRG/ESC to enter into the editing state (if there is a
password, see P07.00 ).The editing state is displayed on two classes of menu, and the order is:
function code group/function code number→function code parameter, press DATA/ENT into the
displayed state of function parameter. On this state, you can press DATA/ENT to save the parameters
or press PRG/ESC to retreat.
