INVT Goodrive300-19 Series Operation Manual page 165

Goodrive300-19 series open loop vector inverter special for hosit
Set
value
57 Inverter enabling
58 Contactor feedback signal
59 Brake feedback signal
60 Joystick zero position signal
Hierarchical reference
61
Hierarchical reference
62
Hierarchical reference
63
Hierarchical reference
64
Hierarchical reference
65
Function
terminal 1
terminal 2
terminal 3
terminal 4
terminal 5
When a multi-function input terminal is set to 57, the
inverter will not run until the enabling signal becomes
valid, otherwise the inverter will not respond to the
running command. If the function is not selected, the
inverter enabling will be valid by default.
P19.01 selects the contactor is controlled by the
inverter. When the terminal function is set to 58, if the
contactor feedback signal is wrong, the inverter will
alarm contactor feedback fault (TbE).
P19.01 selects the brake is controlled by the inverter.
When the terminal function is set to 59, if the brake
feedback signal is wrong, the inverter will alarm brake
feedback fault (FAE).
After the inverter stops, to avoid restart of the inverter,
make sure the joystick returns to zero position (neutral
position). The inverter can restart only when the
joystick returns to zero position and the time is larger
than P19.28.
Note: Signals at zero position are valid only under
joystick mode and hierarchical joystick mode.
6 stages setting can be realized by the combination
st
between the 1 level speed contact given by the
direction command and the states of 5 terminals.
Note: Only when all lower hierarchical contacts
close can the upper hierarchical contacts close. If
the lower hierarchical contacts open while the
upper hierarchical contacts close, alarm the
multi-step speed hierarchical reference fault.
-164-
Basic operation instruction
Instruction
