INVT Goodrive300-19 Series Operation Manual page 237

Goodrive300-19 series open loop vector inverter special for hosit
Model
1.5kW~2.2kW
4kW~5.5kW
7.5kW~11kW
15kW~18.5kW
22kW~30kW
37kW~55kW
75kW~110kW
132kW~200kW
220kW~315kW
Wall installation of 380V 37-110kW inverters
Wall installation of 380V 132-200kW inverters
Wall installation of 380V 220-315kW inverters
Installation dimension of 380V (unit: mm)
W1 W2
126 115
146 131
170 151
230 210
255 237
270 130
325 200
500 180
680 230
-236-
H1 H2
193 175
263 243.5
331.5 303.5
342 311
407 384
555 540
680 661
870 850
960 926
Dimension drawings
Hole size
D1
174.5 5
181 6
216 6
216 6
245 7
7
325
9.5
365
11
360
380 13
