Start-Up And Stop Control - INVT Goodrive300-19 Series Operation Manual

Goodrive300-19 series open loop vector inverter special for hosit
motor 2
Rated current
of
P12.05
asynchronous
motor 2
Stator resistor
of
P12.06
asynchronous
motor 2
Rotor resistor
of
P12.07
asynchronous
motor 2
Leakage
inductance of
P12.08
asynchronous
motor 2
Mutual
inductance of
P12.09
asynchronous
motor 2
Non-load
current of
P12.10
asynchronous
motor 2

7.7 Start-up and stop control

The start-up and stop control of the inverter includes three states: start after the running command
during normal powering on, start after the restarting function becomes valid during normal powering
on and start after the automatic fault reset. Below is the detailed instruction for three startings.
There are three starting methods for the inverter: start from the starting frequency directly, start after
the AC braking and start after the rotation speed tracking. The user can select according to different
situations to meet their needs.
For the load with big inertia, especially in the cases where the reverse rotation may occur, it is better
to select starting after DC braking and then starting after rotation speed tracking.
1. The starting logic figure of starting after the running command during the normal powering on
0.8~6000.0A
0.001~65.535Ω
0.001~65.535Ω
0.1~6553.5mH
0.1~6553.5mH
0.1~6553.5A
-142-
Basic operation instruction
Depend
on model
Depend
on model
Depend
on model
Depend
on model
Depend
on model
Depend
on model
