Goodrive300-19 series open loop vector inverter special for hosit
Set value
37 Motor 2 in operation
Relative parameters list:
Function
Name
code
P06.00 HDO output
P06.01 Y output
P06.02 HDO output
Relay RO1
P06.03
output
Relay RO2
P06.04
output
Function
Detailed instruction of parameters
0: Open collector high-speed pulse output
1: Open collector output
0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: Inverter fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-alarm
15: Underload pre-alarm
16~21: Reserved
22: Running time arrival
23: Modbus communication virtual terminals output
24~32: Reserved
33: Contactor control
34: Brake control
35: Ready for switching off
switching-on frequency at stopping.
Note: The functions 35 and 36 are mainly for:
when the brake adopts external control mode,
inform the control system of switching on/off.
After receiving the command of shifting the motor,
send a feedback signal to the upper computer.
-171-
Basic operation instruction
Instruction
Default
value
0
0
0
1
5
