INVT Goodrive300-19 Series Operation Manual page 137

Goodrive300-19 series open loop vector inverter special for hosit
reverse
rotation in
torque control
Keypad
setting for
upper
P03.16
frequency of
forward
rotation
Keypad
setting for
upper
P03.17
frequency of
reverse
rotation
Upper
electromotion
P03.18
torque
source
Upper
P03.19 braking
torque
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDI setting upper-limit frequency (the
same as above)
5: Multi-step setting upper-limit frequency (the same as
above)
6: Modbus communication setting upper-limit frequency
(the same as above)
7~9: Reserved
0.00 Hz~P00.03 (the Max. output frequency)
0.00 Hz~P00.03 (the Max. output frequency)
0: Keypad setting upper-limit frequency (P03.20)
1: AI1 (100% corresponds to three times of the rated
current of the motor)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: HDI (the same as above)
5: Modbus communication (the same as above)
6~8: Reserved
0: Keypad setting upper-limit frequency (P03.21)
1: AI1 (100% corresponds to three times of the rated
current of the motor)
-136-
Basic operation instruction
50.00Hz
50.00Hz
0
0
