INVT Goodrive300-19 Series Operation Manual page 222

Goodrive300-19 series open loop vector inverter special for hosit
Function
instruction
Fault code of the
inverter
Identifying code of
the inverter
Running frequency
Set frequency
Bus voltage
Output voltage
Output current
Rotation speed
Output power
Output torque
Close loop setting
Close loop feedback
Input IO state
Output IO state
Analog input 1
Analog input 2
Analog input 3
Analog input 4
Read input of
high-speed pulse 1
Read input of
Address
Data meaning instruction
definition
=10:reserved =11:reserved
Bit3: =0:asynchronous motor =1:reserved
Bit4: =0:pre-alarm without overload
=1:overload pre-alarm
Bit5~Bit6: =00: keypad control =01: terminal
control
=10: communication control
2102H See the fault type instruction
2103H Goodrive300-19-----0x011a
3000H 0~Fmax (unit: 0.01Hz)
3001H 0~Fmax (unit: 0.01Hz)
3002H 0.0~2000.0V (unit: 0.1V)
3003H 0~1200V (unit: 1V)
3004H 0.0~3000.0A (unit: 0.1A)
3005H 0~65535 (unit: 1RPM)
-300.0~300.0% (unit:
3006H
0.1%)
-250.0~250.0% (unit:
3007H
0.1%)
-100.0~100.0% (unit:
3008H
0.1%)
-100.0~100.0% (unit:
3009H
0.1%)
300AH 000~01FF
300BH 000~01FF
300CH 0.00~10.00V (unit: 0.01V)
300DH 0.00~10.00V (unit: 0.01V)
-10.00~10.00V (unit:
300EH
0.01V)
300FH
0.00~50.00kHz (unit:
3010H
0.01Hz)
3011H
Compatible with
communication
addresses of
CHF100A and
CHV100
-221-
Communication protocol
R/W
characteristics
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
