INVT Goodrive300-19 Series Operation Manual page 79

Goodrive300-19 series open loop vector inverter special for hosit
Function
Name
code
time
P06 Group Output terminals
P06.00 HDO output
P06.01 Y output
P06.02 HDO output
Relay RO1
P06.03
output
Relay RO2
P06.04
output
Detailed instruction of parameters
The function is used to select the high-speed pulse
output terminals function.
0: Open collector high-speed pulse output: The Max.
pulse frequency is 50.0kHz. See P06.27~P06.31 for
detailed information of the related functions.
1: Open collector output. See P06.02 for detailed
information of the related functions.
0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: Inverter fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-alarm
15: Underload pre-alarm
16~21: Reserved
22: Running time arrival
23: Modbus communication virtual terminals output
24~32: Reserved
33: Contactor control
34: Brake control
35: Ready for switching off
36: Ready for switching on
-78-
Function parameters
Default
Modify
value
◎
0
○
0
○
0
○
1
○
5
