INVT Goodrive300-19 Series Operation Manual page 193

Goodrive300-19 series open loop vector inverter special for hosit
Code
OL2 Inverter overload
SPI Input phase loss
SPO Output phase loss
Rectifying module
OH1
OH2 IGBT overheat
EF External fault
485 communication
CE
Current detection
ItE
Fault
supply is too low;
The setting of motor rated
current is incorrect;
The motor stall or load
transients is too strong
The acceleration is too fast;
Reset the rotating motor;
The voltage of the power
supply is too low;
The load is too heavy;
The motor power is too
small
Phase loss or fluctuation of
input R,S,T
U, V, W phase loss output
(or three phases of the load
are seriously asymmetrical)
Air duct jam or fan damage;
overheat Ambient temperature is too
high;
The time of overload
running is too long
SI external fault input
terminals action
The baud rate setting is
incorrect;
Fault occurs to the
communication wiring;
fault The communication
address is wrong;
There is strong interference
to the communication
The connection of the
control board is not good;
fault
Hoare component is
Cause
-192-
Fault tracking
Solution
supply line;
Reset the rated current of the
motor
Check the load and adjust the
torque lift
Increase the ACC time;
Avoid the restarting after
stopping;
Check the power of the
supply line;
Select an inverter with bigger
power;
Select a proper motor
Check input power;
Check installation distribution
Check the output distribution;
Check the motor and cable
Dredge the air duct or change
the fan;
Low the ambient temperature
Check the external device
input
Set proper baud rate;
Check the communication
connection distribution;
Set proper communication
address;
Change or replace the
connection distribution or
improve the anti-interference
capability
Check the connector and
repatch;
Change the Hoare;
