Goodrive300-19 series open loop vector inverter special for hosit
Set
value
Shifting between A frequency
13
and B frequency
Shifting between the
14 combination setting and A
Shifting between the
15 combination setting and B
16 Multi-step speed terminal 1
17 Multi-step speed terminal 2
18 Multi-step speed terminal 3
19 Multi-step speed terminal 4
20 Multi-step speed pause
21 ACC/DEC time selection 1
22 ACC/DEC time selection 2
23~28
29 Torque control disabling
30 ACC/DEC disabling
Function
frequency
frequency
Reserved
given frequency channel.
This function can realize the shifting between the
frequency setting channels.
th
The 13 function can realize the shifting between A
frequency reference channel and B frequency
reference channel.
th
The 14 function can realize the shifting between A
frequency given channel and the combination setting
channel set by P00.09
th
The 15 function can realize the shifting between B
frequency given channel and the combination setting
channel set by P00.09
The 16 stage speeds can be set by the combination of
digital state of four terminals.
Note: Multi-step speed 1 is the low bit, multi-step
speed 4 is the high bit.
Multi-step Multi-step
speed 4 speed 3
BIT3 BIT2
Shield the multi-step speed selection terminal function
to keep the setting value at the current state.
Select 4 ACC/DEC time by the combination of the 2
terminals.
Terminal Terminal
1 2
OFF OFF
ON OFF
OFF ON
ON ON
The inverter shifts from torque control mode to speed
control mode.
Ensure the inverter will not be affected by the external
