INVT Goodrive300-19 Series Operation Manual page 130

Goodrive300-19 series open loop vector inverter special for hosit
When the user selects the user-defined V/F curve function in Goodrive300-19 series inverters, they
can set the reference channel of voltage and frequency and the corresponding ACC/DEC time, or the
two can combinate to form a real-time curve.
Note: The application of V/F curve separation can be used in many cases with various kinds of
power supply of the inverter. But the users should set and adjust the parameters with caution.
Incorrect parameters may cause damage to the inverter.
Function
Name
code
Speed
P00.00
control mode
Max. output
P00.03
frequency
Upper limit of
P00.04 running
frequency
Lower limit of
P00.05 running
frequency
P00.11 ACC time 1
P00.12 DEC time 1
Rated
frequency of
P02.02
asynchronous
motor 1
Rated voltage
of
P02.04
asynchronous
motor 1
Motor 1 V/F
P04.00
curve setting
Detailed instruction of parameters
1: Sensorless vector control mode 1
2: SVPWM control mode
P00.04~400.00Hz
P00.05~P00.03
0.00Hz~P00.04
0.0~3600.0s
0.0~3600.0s
0.01Hz~P00.03
(the Max. frequency)
0~1200V
0: Straight line V/F curve
1: Multi-dots V/F curve
2: 1.3th power low torque V/F curve
3: 1.7th power low torque V/F curve
4: 2.0th power low torque V/F curve
-129-
Basic operation instruction
Default
value
1
50.00Hz
50.00Hz
0.00Hz
Depend
on model
Depend
on model
50.00Hz
Depend
on model
0
