INVT Goodrive300-19 Series Operation Manual page 94

Goodrive300-19 series open loop vector inverter special for hosit
Function
Name
code
ratio of
dropping
control
Motor
P08.31
shifting
FDT1
electrical
P08.32 level
detection
value
FDT1
retention
P08.33
detection
value
FDT2
electrical
P08.34 level
detection
value
FDT2
retention
P08.35
detection
value
Detailed instruction of parameters
several inverters drive one load.
Setting range: 0.00~50.00Hz
Goodrive300-19 series supports the shift between
two motors. This function is used to select the shifting
channel.
0x00~0x14
LED ones: shifting channel
0: terminal shifting; digital terminal is 35
1: Modbus communication shifting
2~4: Reserved
LED tens: shifting enabling in operation
0: Disabled
1: Enabled
When the output frequency exceeds the
corresponding frequency of FDT electrical level, the
multi-function digital output terminals will output the
signal of "frequency level detect FDT" until the output
frequency decreases to a value lower than (FDT
electrical level—FDT retention detection value) the
corresponding frequency, the signal is invalid. Below
is the waveform diagram:
Setting range of P08.32: 0.00Hz~P00.03 (the Max.
frequency)
-93-
Function parameters
Default
Modify
value
◎
0x00
○
50.00Hz
○
5.0%
○
50.00Hz
○
5.0%
