INVT Goodrive300-19 Series Operation Manual page 238

Goodrive300-19 series open loop vector inverter special for hosit
B.4.2 Flange installation
Model W1
1.5kW~2.2kW 150
4kW~5.5kW 170
7.5kW~11kW 191
15kW~18.5kW 250
22kW~30kW 275
37kW~55kW 270
75kW~110kW 325
132kW~200kW 500
Flange installation of 380V 1.5-30kW inverters
Flange installation of 380V 37-110kW inverters
Flange installation of 380V 132-200kW inverters
Installation dimension of 380V (unit: mm)
W2 W3 W4
115 130 7.5
131 150 9.5
151 174 11.5
210 234 12
237 259 11
130 261 65.5
200 317 58.5
180 480 60
H1 H2 H3
234 220 190
292 276 260
370 351 324
375 356 334
445 426 404
555 540 516
680 661 626
870 850 796
-237-
Dimension drawings
H4 D1 D2
16.5 174.5 65.5
10 181 79.5
15 216.2 113
10 216 108
10 245 119
17 325 167
23 363 182
37 358 178.5
Hole size
5
6
6
6
7
7
9.5
11
