INVT Goodrive300-19 Series Operation Manual page 73

Goodrive300-19 series open loop vector inverter special for hosit
Function
Name
code
Polarity
selection of
P05.10
input
terminals
ON-OFF
P05.11
filter time
Virtual
P05.12 terminals
setting
Terminals
control
P05.13
running
mode
Detailed instruction of parameters
59: Brake feedback signal
60: Joystick zero position signal
61: Hierarchical reference terminal 1
62: Hierarchical reference terminal 2
63: Hierarchical reference terminal 3
64: Hierarchical reference terminal 4
65: Hierarchical reference terminal 5
The function code is used to set the polarity of input
terminals.
Set the bit to 0, the input terminal is anode.
Set the bit to 1, the input terminal is cathode.
BIT8
HDI
BIT4 BIT3
S5 S4
The setting range: 0x000~0x1FF
Set the sampling filter time of S1~S8 and HDI
terminals. If the interference is strong, increase the
parameter to avoid the disoperation.
The setting range: 0.000~1.000s
Enable the input function of virtual terminals at the
communication mode.
0: Virtual terminals are invalid
1: Modbus communication virtual terminals are valid
2~4: Reserved
Set the operation mode of the terminals control
0: 2-wire control 1; the enabling and the direction
combine into one. This mode is widely used. It
determines the rotation direction by the defined FWD
and REV terminals command.
BIT7 BIT6
S8 S7
BIT2 BIT1
S3 S2
-72-
Function parameters
Default
Modify
value
BIT5
0x000
S6
BIT0
S1
0.010s
0
0
○
○
◎
◎
